TE S T ACTION AP PLICAB ILITY
17 Tur n th e ign it ion off.
Discon n ect t he APP Sen sor h a r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or s.
Rem ove t h e E ngin e Con t r ol Rela y.
Con n ect a ju mper wir e bet ween ca vit y 30 a n d ca vit y 87 of t h e En gin e Con t r ol Rela y
conn ect or.
Tur n th e ign it ion on .
Mea su r e th e volt a ge of th e Acceler a t or P eda l Posit ion Sen sor 5-Volt Su pply cir cu it i n
th e E CM h a r ness con n ect or.
Is t h e volt a ge above 1.0 volt ?
All
Ye s → Repa ir th e Acceler a t or P eda l P osit ion Sen sor 5-Volt Su pply cir cu it
for a sh or t to volt a ge.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Repla ce an d pr ogr a m t h e E ngin e Con t r ol Modu le in a ccor da n ce
wit h th e Ser vice In for m a t ion .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
78
DRI V EABI LI T Y - DI ESEL
P 1222-ACC P EDAL P OS ITION SENS OR 1 CKT P LAU SIB ILITY — Co n t in ued
To Next Page
