Symptom List:
P 2240-AB S S TEERIN G ANGLE S ENS OR CAN MESS AGE IMP LAUS I-
BLE 1
P 2240-AB S S TEERIN G ANGLE S ENS OR CAN MESS AGE IMP LAUS I-
BLE 2
Te s t N o t e : Al l s y m p t o m s l i s t e d a b o v e a r e d i a g n o s e d u s i n g t h e s a m e t e s t s .
Th e title fo r th e te sts w ill be P 2240-AB S S TEERIN G AN GLE
SENSOR CAN MESSAGE IMPLAUSIBLE 1.
POSSIBLE CAUSES
CAN BU S CIRCUITS OP E N
STEE RING ANGLE SE NSOR
INTERMITTENT CONDITION
TE S T ACTION AP PLICAB ILITY
1 NOTE: If the ECM detects and stores a DTC, the ECM also stores the
e n gi n e /ve h ic le o p e ra ti n g c o n d i tio n s u n d e r w h ic h th e D TC w a s s e t. S o m e o f
these conditions are displayed on the DRB at the same time the DTC is
displayed.
NOTE: Before erasing stored DTCs, record these conditions. Attempting to
duplicate these conditions may assist when checking for an active DTC.
NOTE: This DTC indicates a communication problem between the Steering
Angl e Sensor a n d t h e EC M.
Tur n th e ign it ion on .
Wit h th e DRBIII",eraseECMDTCs.
Per for m sever a l en gin e r u n cycles, tu r nin g th e ign ition off for a t lea st 20 secon ds
bet ween ea ch en gine r u n cycle.
Wit h th e DRBIII",readtheECMDTCs.
Did t h is DTC set a ga in ?
All
Ye s → Go To 2
No → Go To 3
2 Tur n th e ign it ion off.
Discon n ect t he St eer in g An gle Sen sor ha r n ess con n ect or.
NOTE: This code can be caused by an intermittent problem in the wiring
and connectors to the Steering Angle Sensor. Inspect the Steering Angle
Sensor harness connector and associated wiring for signs of poor terminal
contact.
Tur n th e ign it ion on .
Mea su r e a nd not e t h e volt a ge of bot h CAN Bu s circu it a t t h e St eer in g An gle Sen sor
ha r n ess con n ect or.
Is t h e volt a ge bet ween 2.2 volt s a n d 2.8 volt s for ea ch m ea su r em en t ?
All
Ye s → Test Com plete.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Repa ir th e CAN Bu s cir cu it (s) for a n open .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
190
DRI V EABI LI T Y - DI ESEL
