TE S T ACTION AP PLICAB ILITY
13 Tur n th e ign it ion off.
Discon n ect t he E CM ha r n ess con n ect or s.
Rem ove t h e St a r t er Mot or Rela y fr om t he F u se/Rela y Block.
Mea su r e t h e resist an ce of t h e St a r ter Mot or Rela y Con t r ol cir cu it bet ween th e E CM
ha r n ess con n ect or a n d t h e Fu se/Rela y Block conn ect or.
Mea su r e t h e resist a n ce of t h e Sta r t er Mot or Relay 12-volt Su pply circu it bet ween t he
ECM h a rn ess con n ect or an d t h e Fu se/Rela y Block conn ect or.
Is t h e resista n ce below 10.0 ohm s for ea ch mea su rem en t ?
All
Ye s → Go To 14
No → Repa ir th e St a r t er Mot or Rela y cir cu it(s) for a n open .
Per for m NO START VERIF ICATION - VER-1.
14 Tur n th e ign it ion off.
Discon n ect t he E CM ha r n ess con n ect or s.
Rem ove t h e St a r t er Mot or Rela y fr om t he F u se/Rela y Block.
Mea su r e t h e r esist a n ce bet ween grou n d a n d t h e St a rt er Mot or Relay Con t r ol cir cu it
at t h e Fu se/Rela y Block conn ect or.
Mea su r e t h e resist a nce bet ween gr ou n d a n d t h e St a rt er Mot or Rela y 12-volt Su pply
cir cu it at t h e Fu se/Rela y Block conn ect or.
Is t h e resista n ce below 10.0 ohm s for ea ch mea su rem en t ?
All
Ye s → Repla ce a nd pr ogr a m t h e En gin e Con t r ol Modu le in a ccor da n ce
wit h th e Ser vice In for m a t ion .
Per for m NO START VERIF ICATION - VER-1.
No → Repa ir th e St a r t er Mot or Rela y cir cu it(s) for a sh or t to grou n d.
Per for m NO START VERIF ICATION - VER-1.
245
DRI V EABI LI T Y - DI ESEL
*EN GIN E WILL N OT CRAN K — Co nt i n u ed
