TE S T ACTION AP PLICAB ILITY
8 NOTE: The ECM must have proper power and ground connections for the
fo ll o wi n g t e s t s t o b e v a l id . R e fe r t o Che c k i n g t h e E CM Po wer a n d Gr ound s
in the symptom list.
Tur n th e ign it ion on .
Wit h th e DRBIII",readtheECMDTCs.
Does t h e DRBIII" display a ny ECM DTCs?
All
Ye s → Refer t o sym pt om list for pr oblem s r ela t ed to ECM DTC.
Per for m NO START VERIF ICATION - VER-1.
No → Go To 9
9 Tur n th e ign it ion on .
Wit h th e DRBIII",readtheSKREEMDTCs.
Does t h e DRBIII" display a ny SKREEM DTCs?
All
Ye s → Refer t o sym pt om list for pr oblem s r ela t ed to SKRE E M.
Per for m NO START VERIF ICATION - VER-1.
No → Go To 10
10 Tur n th e ign it ion on .
Wit h th e DRBIII",readtheTCMDTCs.
Does t h e DRBIII" display a ny TCM DTCs?
All
Ye s → Refer t o sym pt om list for pr oblem s r ela t ed to TCM.
Per for m NO START VERIF ICATION - VER-1.
No → Go To 11
11 Per for m t h e Ch eckin g t h e E CM P ower an d Gr ou n ds t est .
Wer e an y pr oblem s fou n d?
All
Ye s → Repa ir a s n ecessa ry.
Per for m NO START VERIF ICATION - VER-1.
No → Go To 12
12 Tur n th e ign it ion off.
Discon n ect t he E CM ha r n ess con n ect or s.
Rem ove t h e St a r t er Mot or Rela y fr om t he F u se/Rela y Block
Rem ove t h e E ngin e Con t r ol Rela y fr om t h e Fu se Block N o.1.
Usin g a jum per wir e, con n ect E n gin e Con t r ol Rela y conn ect or cavit ies 30 a n d 87 in
th e F u se Block N o.1.
Tur n th e ign it ion on .
Mea su r e th e volt a ge of th e St a r t er Mot or Rela y Con t r ol cir cu it .
Is t h e volt a ge above 1.0 volt ?
All
Ye s → Repa ir t h e St a r t er Rela y Con t r ol cir cu it for a shor t t o volt age.
Per for m NO START VERIF ICATION - VER-1.
No → Go To 13
244
DRI V EABI LI T Y - DI ESEL
*EN GIN E WILL N OT CRAN K — Co nt i n u ed
