SH AFT - AX LE SI N GLE REAR WH EEL
REMOVAL-SINGLE REAR WHEEL
(1) Remove wheels.
(2) Detach front bra ke ca ble.
(3) Pull ABS sen sor (18) toget her wit h clamp bush-
ing (19) ou t of bear ing cap (Fig. 6).
(4) Remove brake caliper (16) and disk (10) at rea r
axle (14). At tach br ake ca liper with lines connect ed
in wheel house.
(5) Remove bra ke shoes (2) of par kin g brake.
(6) Remove bra ke con trol cable lock.
(7) Remove bear ing cap bolts (17) and pull axle
sh aft out of a xle t ube (1) (Fig. 6).
(8) Remove seal/gasket.
Fig. 6 AXLE SHAFT
1 - REAR AXLE 11 - BOLT
2 - BRAKE SHOE 12 - WHEEL BOLT
3 - PRESSURE SPRING 13 - BRAKE ADJUSTER
4 - RETURN SPRING 14 - REAR AXLE SHAFT
5 - RETURN SPRING 15 - GASKET
6 - CABLE LOCK 16 - BRAKE CABLE
7 - PARK BRAKE CABLE 17 - BOLT
8 - LOCKING PIN 18 - ABS SENSOR
9 - BOLT 19 - SENSOR BUSHING
10 - BRAKE DISC
VA REAR AXLE 3 - 23
