DISASSEMBLY - SINGLE REAR WHEEL
(1) Remove different ial cover bolts and rem ove
cover (Fig. 33).
(2) Remove upper differ ential side gear (1) an d
sh im (2) (Fig. 34).
(3) Remove fir st set of differ ential pinion gears (1),
spherica l wash ers and m ate sh aft (2) (Fig. 35).
(4) Remove second set of differ ential pinion gea rs
(2), spherica l wa sh ers and mate sha ft (1) (Fig. 36).
Fig. 33 DIFFERENTIAL COVER
1 - BOLTS
2 - COVER
Fig. 34 UPPER SIDE GEAR
1 - SIDE GEAR
2 - SHIM
Fig. 35 FIRST PINION GEARS
1 - PINION GEARS
2 - MATE SHAFT
Fig. 36 SECOND PINION GEAR SET
1 - MATE SHAFT
2 - PINION GEARS
