(5) Remove lower differen tia l side gear (1) and
sh im (Fig. 37).
DISASSEMBLY - DUAL REAR WHEEL
(1) Remove different ial cover bolts and rem ove
cover (Fig. 38).
(2) Remove upper differ ential side gear (1) an d
sh im (2) (Fig. 39).
(3) Remove different ial cross shaft (1) wit h pinion
gear s (2) an d spherica l washer s (3) (Fig. 40).
Fig. 37 LOWER SIDE GEAR
1 - SIDE GEAR
2 - DIFFERENTIAL CASE
Fig. 38 DIFFERENTIAL COVER
1 - BOLTS
2 - COVER
Fig. 39 UPPER SIDE GEAR
1 - SIDE GEAR
2 - SHIM
Fig. 40 DIFFERENTIAL PINIONS
1 - CROSS SHAFT
2 - PINION GEAR
3 - WASHER
