(5) In spect th e clearance, or a slight drag when
rotating th e wheel/rea r disc bra ke r otor (Fig. 39).
(6) In st all rea r wh eels.
(7) Lower the veh icle an d test the park brake sys-
tem to hold th e veh icle.
Fig. 38 STAR WHEEL ADJUSTER
1 - LEFT HAND PARK BRAKE SHOES APPLIED
2 - RIGHT HAND PARK BRAKE SHOES RELEASED
3 - FLAT BLADED TOOL
Fig. 39 ADJUSTING REAR PARK BRAKE SHOES
1 - FRONT BRAKE CABLE
2 - SHOE ADJUSTER
3 - REAR BRAKE CABLES
4 - PARK BRAKE CABLE ADJUSTER
VA BRAKES - BASE 5 - 29
