(8) Unplug wiring conn ector at coolant level sen sor
(Fig. 9).
(9) Detach coolant hose at bot tom right of radiator
(Fig. 9).
(10) Deta ch transm ission cooler lin es at radiator
(Fig. 9).
(11) Remove th e ra diator trim from t he left an d
right (Fig. 9).
(12) Remove ra diator fa n (Refer to7-COOLING/
ENGINE/RADIATOR FAN - RE MOVAL).
(13) Remove bolts secur ing int ercooler to ra diator.
(14) Remove screws and upper r adiator trim from
radiator.
(15) Move condenser /intercooler/power steerin g
cooler assem bly forwar d.
(16) Lift t he ra diat or assembly up and out of th e
rubber grom mets (F ig. 9).
Fig. 9 RADIATOR ASSEMBLY
1 - COOLANT HOSE 8 - ATF LINE
2 - SENSOR HARNESS CONNECTOR 9 - LEFT RADIATOR TRIM PANEL
3 - HYDRAULIC HOSE 10 - RIGHT RADIATOR TRIM PANEL
4 - CHARGE AIR HOSE 11 - RADIATOR
5 - HYDRAULIC HOSE 12 - ATF LINE
6 - RUBBER GROMMET 13 - COOLANT HOSE
7 - COOLANT HOSE 14 - COOLANT RESERVOIR
7 - 18 ENGINE VA
