Replacing External Components
13-12 DSX™ System Service Manual
3 When installing a new float, place the O-ring (Part No. 44000100) over the Float
Switch Harness as shown in Figure 13-4.
Connector
Waste / Float Switch
Harness
O-Ring
Waste Extension Tube
Groove
Float Switch
Figure 13-4 Float Switch Harness
