The Electronics Pod Assembly (EPOD)
DSX™ System Service Manual 17-7
•
•
•
To Replace the Inlet Switch:
1 Remove the wires from the component that is to be replaced. The wiring for these
components is as follows:
The free end of brown Live Harness (Part No. 15001300) from the filter is
connected to the Top Left Live terminal on Inlet Switch (Part No. 50500150).
The free end of blue Neutral Harness (Part No. 15001310) is connected from
the filter to the Bottom Neutral terminal on the Inlet Switch (Part No.
50500150).
The ring terminal of the green/yellow Short Earth Harness (15001290) is
connected from the Inlet Switch to the earth stud using one M4 Shakeproof
Washer and one M4 Hex Nut with washer and nut on top of lug.
2 Remove the inlet switch by pushing it out of the enclosure from the inside.
Note: When replacing the inlet switch, make certain that the fuse (Part No.
50200490) is in inserted into the switch.
