GE LOGIQ S7 Pro - Wired Ethernet from LOGIQ S7 Expert;Pro to a Workstation; Crossover Cable; Connection Via a Peer-To-Peer Network; Connection Via Hospital Network

GE HEALTHCARERAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
3-50 Section 3-12 - Connectivity Setup
3-12-2 Wired Ethernet from LOGIQ™ S7 Expert/Pro to a Workstation
3-12-2-1 Direct Cable Connection from the LOGIQ™ S7 Expert/Pro to a Workstation via a Crossover
Cable.
You will only need a Crossover Cable for network use to connect the two units this way.
1.) Connect one end of the crossed network cable to the network connector on the LOGIQ™ S7 Expert/
Pro.
2.) Connect the other end to the network connector to the Workstation, see the Workstation Service
Manual.
3-12-2-2 Connection via a Peer-to-Peer Network
You will need a network switch and one network cable for each unit connected to the switch.
3-12-2-3 Connection via Hospital Network
3-12-2-4 You will need one network cable to connect the LOGIQ™ S7 Expert/Pro to a wall outlet on the
hospital’s network.
3-12-3 Connection using Wireless Option (R2.x.x or later)
Refer to:
- Chapter 5 for theory.
- LOGIQ™ S7 Expert/Pro Basic User Manual: Chapter 16 Configuring Connectivity.
