GE HEALTHCAREDRAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-37
Section 8-6
Replacement Front Cover
8-6-1 Manpower
1 person, 1 min.
8-6-2 Tools
None required.
8-6-3 Removal Procedure
1.) Simply pull out Front Cover.
Figure 8-15 Front Cover
2.) Front cover is attached using three “latches” as shown below.
Figure 8-16 latches
