GE HEALTHCARERAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
3-10 Section 3-6 - Connection of Auxiliary Devices
Section 3-6
Connection of Auxiliary Devices
NOTE: Normally auxiliary devices and peripherals come pre-installed with the system.
Table 3-7 below outlines hardware installation procedures described in the sub-sections.
NOTE: For more detailed Safety Considerations when connecting auxiliary devices to the LOGIQ™ S7 Expert/
Pro system, please review: Chapter 1 - Auxiliary Devices Safety, on page 1-8.
Table 3-7 Connection Procedures
Sub-section Description Page Number
3-6-1
Connecting the LCD Monitor
3-11
3-6-2
Connecting the Black & White Printer
3-12
3-6-3
Connecting the Color Printer
3-14
3-6-4
Connecting the Secondary “Patient” LCD Monitor
3-16
3-6-5
Connecting the Footswitch
3-18
3-6-6
Connecting the USB Flash Memory Stick
3-19
3-6-7
Connecting the external USB Hard disk (Handydrive)
3-19
3-6-8
General Remarks and Hints when using external USB-Devices
3-20
WARNINGWARNING
!! WARNING:
After each installation, the leakage currents have to be measured according to
IEC 60601-1 respectively UL 60601-1.
CAUTION
!! CAUTION:
Please observe that some printers may not be medical devices! If the Bluetooth Printer and/or
Line Printers are not medical devices, they have to be located outside of the patient
environment (according to IEC 60601-1 / UL 60601-1).
2,5 m
1,5 m
1,5 m1,5 m
