GE LOGIQ S7 Pro - Connecting the Secondary Patient LCD Monitor

GE HEALTHCARERAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
3-16 Section 3-6 - Connection of Auxiliary Devices
3-6-4 Connecting the Secondary “Patient” LCD Monitor
1.) Power OFF/Shutdown the system as described in: Section 3-7-3 on page 3-25.
2.) Connect the Secondary Monitor according to connection scheme (see: Figure 3-8 on page 3-17).
CAUTION
!! CAUTION:
Secondary LCD “Patient” Monitor MUST NEVER be connected to the LOGIQ™ S7 ultrasound
systems mains supply directly!
Always connect it to the supplied Isolation Transformer!
The Secondary Monitor is the only item to be connected to the Transformer.
NOTICE
!! NOTICE:
Secondary Monitor is NOT intended for diagnostic use.
It is an additional device used to allow the patient to watch the proceedings.
Take your time to think about the best position of the monitor in your facilities.
Patients should be able to view the monitor easily and without having to bend or turn around.
NOTICE
!! NOTICE:
Connection to Secondary Monitor is via HDMI cable, but HDMI connector output does NOT carry audio
signal.
