GE HEALTHCARERAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
8-98 Section 8-21 - Replacement of the SOM,HDD and DVR
8-21-6-1 Accessing EEPROM
1.) Exit to Desktop (Refer to Section 5-11 for details).
2.) Start VPD Editor by clicking icon on the desktop “vpdedit”.
Figure 8-108 VPD Editor
3.) Examine the contents of the VPD.
Figure 8-109 VPD
Device Grid The list of devices in the system that support VPD. Click on a Row in this grid
to select a device and view the VPD fields
For Nuri, devices are GFS, BF, PIL, COMExpress (SOM), CPS.
VPD Field Grid A list of data items that make up the selected VPD
To Next Page
