GE HEALTHCAREDRAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-47
8-10-3-2 Removal Procedure - Foot Rest Cover
1.) Remove 3 screws.
Figure 8-30 Foot Rest Cover
8-10-4 Installation Procedure
1.) Parts to be installed in reverse order of removal.
8-10-5 Functional Check
Visual inspection only.
Section 8-11
Replacement Side B/W Printer Tray
NOTE: For this procedure, refer to DIRECTION 5422470, LOGIQ™ S7 Expert/Pro CABINET AND DEVICES
INSTALLATION INSTRUCTIONS.
Test Refer to Note
System Exterior Visual Check Section 4-3-1
