GE HEALTHCARERAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
8-104 Section 8-23 - Replacement of 4D
Section 8-23
Replacement of 4D
8-23-1 Manpower
One person, 1 hour.
8-23-2 Tools
Phillips screwdriver.
8-23-3 Removal Procedure
1.) Remove Rear Panel.
2.) Remove Cable Guards.
3.) Remove EMC Plate.
4.) Pull out CPS/CPS2 Assy.
8-23-4 Installation Procedure
Install components in reverse order of removal.
8-23-5 Functional Check
Refer to Section 4-4 for Functional Diag Test List.
