GE HEALTHCAREDRAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
Chapter 5 - Components and Functions (Theory) 5-9
5-2-4-3 HDMI
NOTE: LOGIQ™ S7 Expert/Pro External display I/O is DVI-D. However, connector shape is HDMI connector.
Table 5-4 Pin Out
Pin number Signal name
1
TMDS Data 2+
2
TMDS Data 2 Shield
3
TMDS Data 2-
4
TMDS Data 1+
5
TMDS Data 1 Shield
6
TMDS Data 1-
7
TMDS Data 0+
8
TMDS Data 0 Shield
9
TMDS Data 0-
10
TMDS CLK+
11
TMDS CLK Shield
12
TMDS CLK-
13
NC
14
NC
15
NC
16
NC
17
GND
18
+5V
19
NC
19 1
18 2
