GE LOGIQ S7 Pro User Manual

GE HEALTHCAREDRAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
Chapter 7 - Diagnostics/Troubleshooting 7-5
Section 7-3
Check Points Voltages
7-3-1 Visual check
7-3-1-1 Common Power Supply (CPS/CPS2)
Turn on mains switch and check green LED inside Power.
NOTE: If LED is on, RTP has full function (all voltages are within the specified range).
Figure 7-6 check green LED inside CPS
