GE HEALTHCAREDRAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
Chapter 7 - Diagnostics/Troubleshooting 7-7
7-3-3 Voltage Measurement Points
1.) Remove Front Cover (no tools required)
2.) Remove CSI Cover
3.) On CSI board, there is 12V measurement point
Figure 7-8 Voltage Measurement Points
CSI
Cover
12V
Measure
Point
