GE HEALTHCARERAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
5-32 Section 5-10 - Common Service Desktop (CSD)
5-10-2-2 Decoding System Temperature and Voltage
NOTE: These are reference only values and therefore, parameters are not constant. Some parameters may
be added/deleted depending on the system configuration, type, and variation.
In general, the first parameter defines data source (board).
"P" in the second parameter denotes "Plus" or "positive" in voltage.
"M" in the second parameter denotes "Minus" or "negative" in voltage.
"V" in the second parameter denotes "decimal point". i.e. 1V5 is 1.5.
Some Example Shown below.
Table 5-12
Parameter Description
BEP_CPU_TEMPERATURE Temperature at CPU core. This parameter used for system temperature monitoring
GFS_LM83 Additional temperature sensor at LM83 chip on GFS.
GFS_GFE Additional temperature sensor on GFS.
GFS_SDEM Additional temperature sensor on GFS.
GFS_BOT Additional temperature sensor on GFS.
GFS_M5V GFS Voltage. Minus 5.0Volt (-5V)
GFS_P3V3_VIDEO GFS Voltage. Positive 3.3Volt (+3.3V) for video signal
GFS_P1V5_PCIE GFS Voltage. Positive 1.5Volt (+1.5V) for PCI-E
GFS_P2V5 GFS Voltage. +2.5V
GFS_P3V3 GFS Voltage. +3.3V
~
BF_DVDD_1V8_1 BF Voltage. 1.8V for AFE Analog/Digital Conversion (group 1)
BF_DVDD_1V8_2 BF Voltage. 1.8V for AFE Analog/Digital Conversion (group 2)
BF_DVDD_1V8_3 BF Voltage. 1.8V for AFE Analog/Digital Conversion (group 3)
BF_AVDD_3V3_1 BF Voltage. 3.3V for AFE chip LNA/VCA (group 1)
~
BF_2V5_CLK BF Voltage. 2.5V for clock
BF_PHVA BF Voltage. Positive HVA
BF_MHVA BF Voltage. Negative HVA
~
PI_3V3_PRB Probe Interface, 3.3V powering Probe
