GE HEALTHCARERAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
2-10 Section 2-3 - Facility Needs
2-3-4 Networking Setup Requirements
2-3-4-1 Stand-alone Unit (without Network Connection)
None
2-3-4-2 Unit Connected to Hospital’s Network
Supported networks:
• Ethernet network connection (R1.x.x/R2 and later)
• Up to 900 Mbps WLAN (R2 and later, optional)
2-3-4-3 Purpose of the DICOM Network Function
DICOM (Digital Imaging and Communications in Medicine) services provide the operator with clinically
useful features for moving images and patient information over a hospital network.
Examples of DICOM services include the transfer of images to workstations for viewing or transferring
images to remote printers. As an added benefit, transferring images in this manner frees up the on-
board monitor and peripherals, enabling viewing to be done while scanning continues.
With DICOM, images can be archived, stored, and retrieved faster, easier, and at a lower cost.
2-3-4-4 DICOM Option Pre-installation Requirements
To configure the LOGIQ™ S7 Expert/Pro ultrasound unit to work with other network connections, the
network administrator must provide some necessary information.
Use the Connectivity Setup Worksheet on page 3-58 to record required information that must include:
Installation see: Section 3-13 "Configuring Connectivity" on page 3-51.
• LOGIQ™ S7 Expert/Pro
Details:
DICOM network details for the LOGIQ™ unit, including the host
name, local port, IP address, AE title and net mask.
• Routing Information: IP addresses for default gateway and other routers in use at site.
• DICOM Application Information: Details of DICOM devices in use at the site, including the DICOM
host name, AE title, DICOM port number and IP addresses.
