GE HEALTHCARERAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
8-46 Section 8-10 - Replacement Side Tray & Footrest Cover
Section 8-10
Replacement Side Tray & Footrest Cover
8-10-1 Manpower
1 person, 15 min.
8-10-2 Tools
Phillips Driver.
NOTE: “Short” type driver preferable for Foot Rest Cover removal/installation.
8-10-3 Removal Procedure
8-10-3-1 Removal Procedure - Side Tray
Figure 8-28 Side Tray and Foot Rest
Procedures are common for both the Left and Right Side Tray.
1.) Remove 2 screws.
Figure 8-29 Side Tray
Side Tray
Foot Rest
