GE HEALTHCARERAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
2-6 Section 2-2 - General Console Requirements
2-2-6 System Specifications
2-2-6-1 Physical Dimensions of LOGIQ™ S7 Expert/Pro
The physical dimensions and weight (without Peripherals) of the LOGIQ™ S7 Expert/Pro unit are
summarized in Table 2-6.
NOTE: Physical dimensions (especially height and depth) depend on control console and monitor positioning.
For more details refer to Chapter 5 - OPIO Positioning, on page 5-24.
2-2-6-2 Acoustic Noise Output
max. 50 dB(A)
2-2-6-3 Electrical Specifications
Please refer to Section 2-2-2-1 "LOGIQ™ S7 Expert/Pro Power Requirements" on page 2-3.
Table 2-6 Physical Dimensions and Weight (without Peripherals)
Height Width Depth Weight
1750 mm (max)
1115 mm (min) *
620 mm (console)
500 mm (Operator Panel)
856 mm 90 kg
* with low cabinet option
