GE HEALTHCAREDRAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
Chapter 9 - Renewal Parts 9-3
Section 9-3
Parts List Groups
Figure 9-1 Console Views
Table 9-2 Mechanical and user accessible parts
Item Part Group Name Table Number Description
100-
109-
Plastics Covers (Front/Sides/Rear)
Table 9-3 on page 9-4 Housing Covers
200-
202
LCD Monitor
Table 9-4 on page 9-5 Monitor and its covers
301-
323
OPIO
Table 9-5 on page 9-9 User interface parts
401-
416
Nest Box Parts
Table 9-6 on page 9-13
Main board modules
Including front/back end boards
501-
516-
Mechanical Parts
Table 9-7 on page 9-15 Mechanical Parts and speaker
701-
707
Options
Table 9-8 on page 9-17
811-
812
Optional Peripherals and Accessories
Table 9-9 on page 9-18
B/W Printer, Color Printer, Line Printer
Bluetooth
Probes
Table 9-10 on page 9-19 Probes
930-
941
Power Cord
Table 9-11 on page 9-23 Power Cord
