GE HEALTHCARERAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
5-10 Section 5-2 - General Information
5-2-4-4 RJ45
1000Base-T, 100Base-T, 10Base-T
5-2-4-5 MiniJack
Normal Audio L/R GND pin assign Line out
5-2-4-6 AC Inlet
Figure 5-7 AC Inlet
Table 5-5 Network Connector, RJ45 Modular 8 Pin
Pin No Output Signal Description
1 ETHER TD Ethernet RD+
2 ETHER TD Ethernet RD-
3 ETHER RD Ethernet TD+
6 ETHER RD Ethernet TD-
Others NC No connection
100-120V/220-240V AC
