GE HEALTHCAREDRAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
Chapter 5 - Components and Functions (Theory) 5-25
5-7-4 Air Flow Distribution
NOTE: Clean the Air Filter periodically.
Through the filter grid on the front of the system, air flow into the LOGIQ™ S7 Expert/Pro scanner. By
means of the 1 FAN, air is blown through the nest-box, and the warm air exits the scanner through holes
in the left side panel and rear of the system.
Figure 5-9 Air Inlet/Outlet at LOGIQ™ S7 Expert/Pro
Main Air
inlet
(Filter grid)
Main Air
Outlet
(Rear)
(Side)
