GE HEALTHCARERAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
8-134 Section 8-32 - Replacement of Filter
8-31-4 Installation Procedure
In reverse order of removal.
8-31-5 Functional Check
1.) Visually check LCD monitor.
2.) LCD Arm Test. (Refer to Section 4-3-2-2).
Section 8-32
Replacement of Filter
8-32-1 Manpower
1 person, 2 minutes.
8-32-2 Tools
None Required.
8-32-3 Removal Procedure
1.) Remove Front Cover.
2.) Pull out Filter upward.
8-32-4 Installation Procedure
In Reverse Order.
8-32-5 Functional Check
Visual inspection Only.
Section 8-33
Replacement of SW CD set
8-33-1 Manpower
1 person, 3 minutes.
8-33-2 Tools
Phillips Screw Driver.
8-33-3 Removal Procedure
1.) Remove Rear Cover.
2.) CD is placed on Rear Cover.
8-33-4 Installation Procedure
Reverse Order.
8-33-5 Functional Check
Visual inspection Only.
