GE HEALTHCAREDRAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
Chapter 4 - Functional Checks 4-3
1.) Check for no loose or cracked parts on above locations. (see: Figure 4-1)
1. LCD Monitor 8. Probe holder (Option) 15. Probe port - 4 active
probe ports
2. Touch panel 9. DVD Drive 16. Audio speaker
3. USB port 10. BW Printer 17. Gel warmer or Gel Holder
4. Probe holder 11. Color printer or Drawer 18. ECG connector
5. A/N Keyboard 12. Foot rest 19. Articulating arm
6. Control panel swivel
button
13. CW pencil probe port 20. External I/O panel
7. Control panel up/down
button
14. Side tray (Option)
