GE HEALTHCARERAFT LOGIQ™ S7 EXPERT/PRO
DIRECTION 5460683, REVISION 3 DRAFT (JUNE 25, 2014) SERVICE MANUAL
3-24 Section 3-7 - Completing the Set Up
NOTE: Startup GE Healthcare wallpaper with progress bar may differ depending on product type and release.
5.) The software initiates and sets up the Front-End electronics and the rest of the scanner
(incl. the clicking sound of the relays on the PIL board).
6.) The Keyboard backlight is lit.
7.) As soon as the software has been loaded, the 2D screen is displayed on the monitor.
Figure 3-13 GE Healthcare wallpaper with progress bar (R2.x.x or later)
