iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
103
Table 4.4.3.1-1 H.323 VOIP ATTRIBUTES
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
RAS Uni-cast IP
Address
This parameter defines the Unicast IP address for RAS
Information of Gatekeeper.
IP Address
82.134.80.2
RAS Keep Alive
Time
To maintain a connection, the system and Gate Keeper must
exchange RAS Information prior to the expiration of this timer.
001-999
(seconds)
120
RAS Number Plan
Prefix
The numbering plan for Calling Numbers in RAS Setup.
Max. 23
digit
9
RAS Light RRQ
Usage
The system can be assigned to use the simple RRQ
(Registration Request) message (ON) or the full RRQ
message (OFF).
OFF
ON
OFF
RAS Gateway ID
The Gatekeeper ID.
128
characters
Fail Over Usage
If an H.323 call fails to set up in the ‘Call Setup No Response
time’ below, the system will attempt to place the call on the
Failover CO/IP group also defined below.
OFF
ON
OFF
Call Setup No
Response Time
When Failover is enabled, the system places the fail-over call if
this timer expires before the system receives a response to
setup messages.
0, 3-15
Sec.
5
Failover CO Group
Number
The system will place the Fail-over call employing a CO/IP line
from the assigned CO/IP Line Group.
eMG80/100:1-21, eMG800:1~201, UCP:1~201
Refer to
description
VOIP(VOIU) GW Port Usage
Q.931 Port Range
IP-Binding H.323 signaling option: Q.931 TCP Port Range.
TCP port
2048-2559
H.245 Port
Range IP-Binding H.323 signaling option: H.245 TCP Port
Range.
TCP port
2560-3071
RAS Port Range
IP-Binding H.323 signaling option: RAS UDP Port Range.
UDP port
2048-3071
Media Port Range
IP-Binding media option: Media UDP Port Range.
Default: eMG80/100:6000-7036, eMG800:6000-14400,
UCP:6000-19972
UDP port
Refer to
description
Data Sharing Port
Range
IP-Binding option: Data Sharing TCP Port Range.
TCP port
8500-8548
External CODEC Priority Configuration
External CODEC
Priority
Configuration
The system supports five Codecs and, for negotiating
purposes, the priority of each can be defined. Codecs not
assigned a consecutive priority are not available during
negotiations with the host.
None/
g.711-u/
g.711-a/
g.723.1/
g.729/
g.729a
None
