iPECS UCP600 - MSN Table - PGM 202

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
240
4.4.7.3 MSN Table - PGM 202
Selecting MSN Table will display the MSN Table data entry page. For convenience, the copy, paste, and drag
are available to enter or modify data. Click the [Save] button after changing Value.
Enter Index Range: eMG80/100: 1-500 / eMG800: 1-1500 / UCP: 1-2400
Figure 4.4.7.3-1 MSN Tables
When an ISDN Line assigned for DID operation receives an incoming call, the call will be routed to a station
based on the Flexible DID Table Index assigned in the MSN Table. Each iPECS configuration has a different
capacity, as indicated by the entry range in the following table.
Table 4.4.7.3-1 MSN TABLE ATTRIBUTES
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
CO Line Range
Enter the CO Line Range.
eMG80/100:1-74, eMG800:1-600, UCP:1-998
Refer to
description
None
Index of Flexible
DID Table
Index to the Flexible DID Table.
0~9999
None
Called
Telephone
Number
The call is routed based on the DID Table index entered above
when the received MSN number matches this entry.
Max. 23 Digits(Include * and #)
Refer to
description
None
Company Name
Table Index
The system provides the company name of the MSN table for
MSN calls according to assigning the Company Name Table
(241).
0-100
(0:Station
Name)
None
