4.4.7.4 ICLID Route Table - PGM 203
Selecting ICLID Route Table will display the ICLID Route Table data entry page. Click the [Save] button after
changing the field.
Figure 4.4.7.4-1 ICLID Route Table
The system can employ ICLID (Incoming Calling Line Id) to determine the routing of incoming external calls.
Each CO/IP Line, including DID Lines and ACD group calls, may be assigned to employ ICLID routing. The
system will compare the received ICLID to entries in the ICLID Route Table and, if a match is found, will route
the call to the destination defined in the ICLID Ring Assignment Table index assigned here.
Table 4.4.7.4-1 ICLID ROUTE TABLE ATTRIBUTES
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
ICLID Ring
Assign Index
Index to the ICLID Ring Assignment Table that determines the
call routing.
eMG: 001~250, UCP: 001~500
Refer to
description
None
Caller
Telephone
Number
ICLID (Incoming Caller Id) to match for the index. If the Caller
Id matches the Table entry, the index is used to select the
route.
24 Digits
None
Caller Name
ICLID name that is sent by the system to the destination for the
ICLID routed call.
12characters
None
Ring Tone
If the received Caller Id matches the Caller Telephone
Number, the Ring tone selected here is employed for the call
alert.
01 ~ 16
Ring Tone
