iPECS UCP600 - Multi-Cast Ip;Port - PGM 165

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
164
4.4.5.13 Multi-cast IP/Port - PGM 165
Selecting Multi-cast IP/Port will display the Multi-cast IP/Port data entry page. Click the [Save] button after
changing Value.
Figure 4.4.5.13-1 Multi-cast IP/Port
The system employs Multi-cast to send BGM, MOH, paging, and Push-To-Talk packets.
Employing a single multi-cast packet reduces the overall LAN traffic. In some cases, specifically, when multiple
systems are connected to the same default gateway (router), defining different IP ports for each system may
be advantageous.
Table 4.4.5.13-1eMG80/100MULTI-CAST IP/Port
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
BGM Internal
RTP and RTCP ports for internal BGM.
0000-9999
8100
(8101)
BGM External 1
RTP and RTCP ports for external BGM 1.
0000-9999
8102
(8103)
BGM External 2
RTP and RTCP ports for external BGM 1.
0000-9999
8104
(8105)
Internal Page 1
RTP and RTCP ports for Internal Page 1.
0000-9999
8106
(8107)
Internal Page 2
RTP and RTCP ports for Internal Page 2.
0000-9999
8108
(8109)
Internal Page 3
RTP and RTCP ports for Internal Page 3.
0000-9999
8110
(8111)
Internal Page 4
RTP and RTCP ports for Internal Page 4.
0000-9999
8112
(8113)
