4.4.9.16 Registration Table - PGM 235
Selecting Registration Table will display the Registration data entry page. Click the [Save] button after
changing Value.
Figure 4.4.9.16-1 MAC Registration Table
When multiple iPECS systems are located on the same LAN, it may be desirable to register add-on devices
employing the Registration Table.
Table 4.4.9.16-1 MAC REGISTRATION TABLE
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
MAC Address
Enter MAC address of a device to register
000000000000
Maximum Port
Enter a maximum number of ports (channels) for the
device.
00-99
00
Device ID
A device ID may be entered for registration. The Device ID
available is shown at the bottom of the System Overview
Web page.
0-255
0
