4.3.11.3 TNET LM ATTRIBUTES – PGM 332
The CM (Central MPB/MPB) must be programmed with the MAC and IP address of each LM (Local MPB) in
the Centralized Control network and the maximum configuration of each LM.
The port counts define the ports allocated in the CM database for use by devices registered to the LM.
The number of ports defined in the database of each LM, seesPGM 331, must be equal to or less than the
ports defined in the CM for the LM to register properly.
VoIP channels are needed to support RTP Packet relay or codec translation between other devices. The CO
port count must include any VoIP channels required.
TNET LM ATTRIBUTES
ENTER BIN NO(01-15)
Press the [PGM] button and dial 332.
TNET LM(01) ATTRIBUTES
PRESS FLEX KEY (1- 4)
Use the dial pad to enter the bin number associated with the LM.
Press the Flex button, 1~4 for the desired setting. Refer to Table 3.3.11.3-1.
Use the dial-pad to enter the required data. Refer to Table 3.3.11.3-1.
Press the [Save] button to store the new data.
Table 3.3.11.3-1 TNET LM ATTRIBUTES (PGM 332)
LM(01) MAC ADDRESS
0000000000000
This field defines the MAC address of the LM
that will be part of the TNET environment and
is used by the CM for authorization.
LM(01) IP ADDRESS
0 .0 .0 .0
This field displays the IP address of the LM.
LM(01) IPKTS PORT
(0001 - 9999) :5588
In the TNET environment, the IP KTS
protocol signaling the UDP port is defined. At
present, this field is not used, do not change
this port number.
LM (01) TOTAL PORT
(000 – 999) : 000
This field defines the total number of ports the
LM will request to be allocated by the CM for
devices attached to the LM.
This value must be equal to or more than the
available port count in the LM.
LM (01) MULTICAST IP
239.20.19.1
This field defines the multicast IP address
that could be used in the TNET branch site.
