4.4.9.5 Digit Conversion Table - PGM 270
Selecting Digit Conversion Table will display the page shown. Click the [Save] button after changing Value.
EnterTable Number: eMG80/100: 1-15 / eMG800: 1-32 / UCP: 1-32
Figure 4.4.9.5-1 Digit Conversion Table
The Digit Conversion Table index is assigned to the Station and CO line. In addition, as necessary, digit
conversion can be applied according to the Apply Time Type (Unconditional, Day/Night/Timed, or LCR/Time).
Each Table has 200 entries of up to 24 digits. Entries in the Tables can be any digit (0-9), “*,” “#,” X” (Mask
Digit), “F” (Ignore digit). Each Index can be applied by Apply Option (All/Station/CO line/Disable).
Table 4.4.9.5-1Digit Conversion table
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
Apply time
The Apply time type is to be applied when the dialed digit is
dialed.
Unconditional, Follow Day/Night/Timed, Follow LCR
Refer to
description
Un
conditional
Auto Ring
Mode table
Day/Night/Timed Time Table Index.
N/A, eMG:00-15, UCP:00-100
Refer to
description
Dialed digit
It is the dialed digit to be compared.
Max. 24
Digits
Changed digit
Changed digit.
Max. 24
Digits
ARS Digit
Suppose a selected path is not available for some reason (All
Busy, Line Fault, etc.) after digit conversion. In that case,
Alternative Route Selection (ARS) will connect calls using
predefined designated ARS digits in the digit conversion table.
Max. 24
Digits
Changed CLI
The different CLI as Changed CLI according to Dialed digit can be
sent.
Max. 25
Digits
Apply option
The Apply Option can be applied according to the caller.
All, Station, CO line, Disable
Refer to
description
All
