4.4.11.2 H.323 CO Group Attributes -PGM 327
Selecting H.323 CO Group Attributes will display the data entry page. Click the [Save] button after changing
Value.
Enter Group number: eMG80/100: 1-20 / eMG800: 1-200 / UCP: 1-200
Figure 4.4.11.2-1 H.323 CO Group Attributes
The VOIP channels are used for Distributed Networking, SIP or H.323 networks, and remote iPECS devices.
When the standard H.323 VoIP protocol is employed for an external VoIP call, several attributes of these
channels can be assigned.
The H.323 call set-up mode and tunneling (H.245 Encapsulation) can be established. Also, for H.323 support,
a RAS (Registration, Admissions, and Status) channel can be defined. The RAS channel IP addresses
(unicast and multicast), IP port Numbering Plan and other H.323 set-up characteristics are defined.
Table 4.4.11.2-1 H.323 CO Group Attributes
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
H.323 Setup mode
H.323 IP calls can be set up using the H.323 normal or Fast
Start mode.
Fast
Norm
Fast
H.323 Tunneling
mode
H.323 IP calls can be set up using the H.245 encapsulation
(Tunneling).
OFF
ON
ON
H323 Early Media
(early H245)
This feature is the ability of two user endpoints to
communicate before the call is actually established in
normal call mode. This feature is not used when 'H323
Setup Mode' is 'Fast.'
 Setup: The caller party tries to open early media on
receiving the Setup message.
 Proceeding: Calling party tries to open early media on
receiving the Proceeding message.
 Alerting: Calling party tries to open early media on
receiving the Alerting message.
Refer to
description
