4.3.2.6 8-Digit Table
We can support it more 4 digits for station number. Station numbering should not conflict with the numbering
plan. It is consists of prefix digits and adds digits. Prefix digits can have up to 4 digits, and Add digits can have
up to 4 digits.
PROCEDURE
DIGIT 8 TBL
ENTER TBL NO(01-10)
Press the [PGM] button and dial 238.
Digit 8 TBL 1 : Empty
Use the dial-pad to enter the desired table number.
Press the desired Flex button; refer to Table 3.3.2.6-1.
Use the dial-pad to enter the required data.
Press the [Save] button to store the data entry.
Table 3.3.2.6-1 8-Digit Table (PGM 238)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
TBL 1 : SET 8 digit
8 digit 1: …....
The user may be allowed to enter the prefix
digits using character assign method.
(ex : 4+0 → 4)
Up to
4digits
N/A
2
TBL 1: SET ADD DIGIT
ADD DIGIT : 0
The user can be allowed to add digits. (ex: if
it’s set 3, prefix digits + xxx)
Up to 4
digits
0
