iPECS UCP600 - Network Supplementary Attribute - PGM 321

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
257
4.3.10.2 Network Supplementary Attribute – PGM 321
PROCEDURE:
NET SUPPLEMENTARY ATTR
PRESS FLEX KEY (1-9)
Press the [PGM] button and dial 321.
Press Flex button 1~9 for the desired setting. Refer to Table 3.3.10.2-1.
Use the dial-pad to enter the required data. Refer to Table 3.3.10.2-1.
Press the [Save] button to store the new data.
Table 3.3.10.2-1 NETWORK SUPPLEMENTARY ATTRIBUTE (PGM 321)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
NET TRANSFER MODE
(1:RERT/0:JOIN) :REROUT
Select type for Transfer and Call
forward – Rerouting or Join
1: RERT
0: JOIN
REROUT
2
TCP PORT FOR BLF
(9500-9999) :9500
TCP port for sending BLF message to
BLF Manager
0000-9999
9500
3
UDP PORT FOR BLF
(9500-9999) :9501
UDP port for sending BLF message to
BLF Manager
0000-9999
9501
4
BLF MANAGER IP
0 .0 .0 .0
IP Address of BLF Server used only
when iPECS is configured with LDK
systems for Voice Networking
0.0.0.0
5
DURATION OF BLF STS
(01-99) 100 mm sec : 10
Duration of BLF status message
sending to BLF Server.
01-99
(msec)
10
6
MULTI CAST IP
0 .0 .0 .0
IP address of Multicast for BLF service.
0.0.0.0
7
NET TRANS FAULT RCL TMR
(001-300)sec : 010
Network transfers fault recall timer to be
used when no responses from other
systems.
001-300
(seconds)
10
8
VOIP CALL REROUTE CO GR
(00-20) : 00
SIP outgoing call is rerouted via
alternative backup CO line when a call
is failed, or there is no answer for 3
seconds.
eMG80/100:1-20, eMG800:1~200
Refer to
description
00
9
BLF SERVICE USAGE
(1:ON/:OFF) : ON
Enable/disable for BLF manager
function.
0: OFF
1: ON
ON
