4.4.10.2 Network Supplementary Attributes - PGM 321
Selecting Network Supplementary Attributes will display the Network Supplementary Attributes entry page.
Click the [Save] button after changing Value.
Figure 4.4.10.2-1 Network Supplementary Attributes
Table 4.4.10.2-1 NETWORK SUPPLEMENTARY ATTRIBUTES
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
Net Transfer
Mode
Call Forward and Transfer over the network employs the selected
Rerouting or Join method
REROUT/
JOIN
REROUT
TCP Port for
BLF
The TCP/IP port for BLF message packets to BLF Manager is
defined.
9500-9999
9500
UDP Port for
BLF
The UDP port for BLF message packets to BLF Manager is defined.
9500-9999
9501
BLF Manager
IP
The IP Address of the BLF Manager server is required when iPECS
UCP is configured with eMG systems in the Network.
0.0.0.0
Duration of BLF
State
The system sends BLF messages to the BLF Manager at intervals
of this timer.
01-99
(Sec.)
10
Multicast IP
The multicast IP address for BLF service.
0.0.0.0
Net Trans
Recall timer
When a call forward or transfer does not receive a response from
the Network system, the call recalls the transferring party at the
expiration of this timer.
001-300
(msec)
10
NET Reroute
CO Group
If an outgoing SIP call receives no response after the expiration of
this timer, the call is rerouted to the alternate CO line.
eMG80/100:0~20, eMG800:0~200, UCP:0~200
Refer to
description
BLF Service
Usage
BLF Manager support must be enabled for use.
OFF, ON
ON
