iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
393
4.5.4 SMDR
The iPECS system can download SMDR data in an SYLK format file (.slk). The file is compressed using the
“gz” file format. After unzipping, the file can be opened under any common spreadsheet application. The
system will provide a view of SMDR data for the station range entered in the Web page Figure. This page may
also be employed to delete SMDR records for the station range entered.
Figure 4.5.4-1 SMDR Access
4.5.5 File System
4.5.5.1 File View & Delete
The File View & Delete page displays various files stored in the file system memory. To delete a file, check the
box for the file and click [Delete]. Files can also be downloaded to the PC using the [Download] button to the
right of the file name. Note the system requires the files displayed in grey, and the system will not allow
deletion of these files.
Figure 4.5.5.1-1 File View and Delete
4.5.5.2 File System Information
The File System Information page displays the disk status, including the total and free disk space as shown in
the figure. Use this page to determine if the free space on the disk is sufficient for uploading Upgrade files,
section 4.5.1.
Figure 4.5.5.2-1 File System Information
