iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
350
4.4.13.6 Zone Attribute – PGM 439
Selecting the Zone Attributes returns the Zone Attributes data input page. Enter the desired zone number
range and click [Load]to assign Zone characteristics. Use the checkmark to indicate which attributes to
modify; checked attributes are stored by clicking the [Save] button.
Figure 4.4.13.6-1 Zone Attributes
The nation code, codec, and VMIU/VMIB assigned for a Zone will be employed by all devices in the Zone
unless a different entry is made in Device Zone data. If the Device Zone data is default or assigned by the
MPB, the Zone data will take precedence.
The Zone Attributes define when and which VoIP channels to use for RTP packet relay. Local VoIP channels
are assigned to perform the packet relay function, and the user can be defined as “if needed” or use the
assigned RTP Relay Group. For “if Need,” the MPB will employ the IP KTS STUN protocol to determine when
packet relay is required. If assigned “RTP Relay Group,” packet relay will always be employed for RTP packet
receipt.
E.164 Management Information
(Outgoing Dial Number : E164-> Normal) (Incoming CLI Number: Normal ->164)
