iPECS UCP600 - Virtual Dip-Switch - Pgm 453

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
278
4.3.17 VIRTUAL DIP-SWITCH — PGM 453
The Virtual Dip Switch is employed to change from in-band to SMDI for External Voice Mail communications
and manually poll each IP KTS device.
PROCEDURE:
VIRTUAL DIP SWITCH
PRESS FLEX KEY (1-6)
Press the [PGM] button and dial 453.
To enable the trace, press desired Flex button 1~6. The Flex button
LEDs indicate Dip switch setting, On/Off. Press the desired Flex
button to toggle setting,
- LED On: enabled
- LED Off: disabled
To enable call trace, press the [Save] button.
Table 3.3.17-1 VIRTUAL DIP-SWITCH (PGM 453)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
VIRTUAL DIP SWITCH
DEVICE POLLING: (ON)
‘Device polling.’ If enabled (On), the system
will check each registered device,
Gateway/Board, and iPECS Phone to
determine if the device is alive or not.
0: OFF
1: ON
ON
2
VIRTUAL DIP SWITCH
SMDI SETTING: (OFF)
SMDI setting is enabled for output.
0: OFF
1: ON
OFF
3
VIRTUAL DIP SWITCH
MULTICAST LED: (OFF)
If this value is set, the LED commands from
MPB will be sent to Gateway/boards and
terminals in the multi-cast mode.
0: OFF
1: ON
OFF
4
VIRTUAL DIP SWITCH
AUTO NEGO: (MANUAL)
This field enables the negotiation of speed
between the LAN switch port and the
system.
0: AUTO
1: MANUAL
MANUAL
5
VIRTUAL DIP SWITCH
FULL-HALF: (FULL)
The duplex mode of LAN connections can
be set according to this field.
0: FULL
1: HALF
FULL
6
VIRTUAL DIP SWITCH
10-100 TX: (100)
The speed of the Ethernet interface is
established based on this field, 10 Base T
or 10/ 100 Base T.
0: 100
1: 10
100
