4.3.11.5 TNET LM External Contact Attributes – PGM 334
Each LM incorporates relay contacts, which can be employed as a Door Lock Release. The contact activates
a 3rd party Door Lock Release mechanism activated by dialing the Door Unlock code at a local station. Note
assigning other functions to the contact may cause an unexpected operation.
TNET LM EXT CONTACT
ENTER BIN NO (01-15)
Press the [PGM] button and dial 334.
The range is : eMG80/100 : 1-15 / eMG800: 1-32
LM(01) EXT CONTACT
PRESS FLEX_KEY (1-4)
Select Flex button 1~4 for the desired External Control contact.
Use the dial-pad to enter desired data.
- 1. LBC + station number, (ex. 150)
- 2. Door Lock Release
- 3. External Page 1 access
- 4. External Page 2 access
Press the [Save] button to store the External Contact data entry.
