74
4.3 Procedure for Data Entry
The following sections provide specific instructions for entering data from the Admin Station once in the
Program mode. Each section provides descriptive information, step-by-step instructions, and Tables for
determining appropriate entries.
4.3.1 System ID —PGM 100
Under System ID, the country is identified using the international dial codes (NATION CODE). If the
NATIONC\defaults, gain, frequencies, and other system characteristics specific to the country and regional
regulatory PGM
To change the NATION Code on eMG:
1) Set the MPB Dip-switch 1 pole 2 to the ON position,
1) Follow the procedure below to modify the NATION code
2) Press the reset button on the KSU, power the system Off and On, or use PGM 450 to initialize the
system.
3) After initialization, reset switches as needed. Dip-switch 1 pole 2 should be OFF.
A twenty-four (24) character SITE NAME and the local Area Code are also defined in this program. The SITE
NAME is primarily useful for the installer/programmer as a reference to the customer.
In addition, the system can be programmed to select one of eight (8) Flexible Number Plans under this
program. Refer to Appendix B. Individual items from the selected Numbering Plan can be changed under
Flexible Numbering Plan part A to D PGM 106 to 109- in section 3.3.2.5.
PROCEDURE
SYSTEM ID
PRESS FLEX KEY (1-6)
Press the [PGM] button and dial 100.
Select the desired Flex button (1~5), refer to Table 3.3.1-1. For
COUNTRY CODE, refer to Table 3.3.1-2 for appropriate entries.
Use the dial-pad to enter desired System Id data. For System Reset,
button 5, press [Save] to reset the System Id to default.
To store the System Id data, press the [Save] button.
Table 3.3.1-1 SYSTEM ID (PGM 100)
BTN
DISPLAY
REMARK
RANGE
DEFAULT
1
COUNTRY CODE
1
Refer to Table 3.3.1-2 below.
Note system must be re-initialized if
changed.
4 digits
1
2
CUSTOMER SITE NAME
………………………………….
Refer to Table 3.1.2-1 for alphanumeric
dial-pad entries.
24
character
3
MY MULTI AREA CODE
ENTER TABLE NO(00-40)
Enter the area code of the installed site.
6 digits
