4.3.11.4 FoPSTN Attributes – PGM 333
The Fail-over function allows the systems in a Centralized Control network (TNET) environment to complete
calls from system to system over a PSTN (analog or digital) line should the WAN connection to the CM fail.
A CO Gateway/Board must be registered to the LM for local control and access to CO services. Users may
call others normally, and the call is routed over CO facilities to the remote CM.
When calls are directed to a DID line at the receiving system, the system will select a line from the assigned
CO Group and dial the Tel Number with the station number dialed as the trailing digits.
PROCEDURE:
FoPSTN ATTRIBUTES
PRESS FLEX KEY (1–3)
Press the [PGM] button and dial 333.
Press the Flex button 1~3 for the desired setting. Refer to Table 3.3.11.4-1.
For Flex button 1 enable or disable FO. For Flex button 2, press the [Save]
button to reset the FO table. For Flex button 3, dial the table bin number to
input data.
For Flex button 3, use the dial-pad to enter the required data. Refer to Table
3.3.11.4-1.
Press the [Save] button to store the new data.
Table 3.3.11.4-1 FAIL-OVER ATTRIBUTES (PGM 333)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
ENABLE FoPSTN
(1:ON/0:OFF) : ON
This field is used to enable or disable Fail-
over operation from the CM or LM.
0: OFF
1: ON
OFF
2
INIT FoPSTN TABLE
PRESS [Save] KEY
This field is used to initialize the FO table.
3
FoPSTN ATTRIBUTES
ENTER BIN NO(000-199)
3-1
FoPSTN 001 NUM PLAN
xxxxxxxx
Station numbers are associated with the
remote system. A range can be indicated by
using “*” to indicate the range.
Max 8
digits
3-2
FoPSTN 001 CO GROUP
GRP NO (00-21) : 01
This field defines the CO Group of the local
system that will be used to place calls to the
stations entered in the FO Numbering Plan
should WAN failure occurs.
eMG80/100:1~20, eMG800:1~200
Refer to
description
3-3
FoPSTN 001 TEL NUMBER
xxxxxxxxxxxxxxxxxxx
This field defines the telephone number the
system should dial to place a call to the
stations entered in the FO Numbering Plan,
should Wan failure occur. An “*” may be
entered as a wild-card to indicate insertion of
the dialed station number.
