4.4.4.1 Common Attributes - PGM 140
Selecting Common Attributes will display the Common Attributes data input page. Enter a valid CO range and
click [Load] to enter the Common Attributes data. Use the checkmark to indicate which attributes to modify;
checked attributes are stored by clicking the [Save] button.
Enter CO Range: eMG80/100: 1-74 / eMG800: 1-600 / UCP: 1-998
Figure 4.4.4.1-1 Common Attributes
Common Attributes define various characteristics of CO lines facilities under the control of the system. Most
characteristics require an On/Off setting; refer to the following table. Specific descriptions for Class-of-Service
and CO line Call Metering tones are provided in Table 4.4.4.1-3.
Table 4.4.4.1-1 Common Attributes
Each CO Line is assigned a type, Normal, DID, or TIE Line.
Normal, DID, TIE, Unused
Each CO/IP Line is assigned to a group; grouping should be
based on the Line type, technology, and COS.
0-21(eMG80/100), 0-201(eMG800), 0-201(UCP)
Each CO/IP Line is assigned a Class-of-Service that interacts with
the Station COS, refer to Table 4.4.4.1-2
CO COS 1: Station COS applies
CO COS 2: Exception Table A governs
CO COS 3: Exception Table B governs
CO COS 4: Restricts LD calls & Exception Table C
CO COS 5: Overrides Station COS 2~6 with no restrictions.
