iPECS UCP600 - LCR Table Initialization - PGM 223

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
293
Table 4.4.9.3-1 LCR DIGIT MODIFICATION
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
CO/IP Group
This entry defines the CO/IP Group that the system will
attempt to use for the call.
eMG80/100:01-21
eMG800:01-201
UCP: 01-201
1
Alternative DMT
Index
This entry defines an Alternate Digit Modification Table
Index to use if no path is available in the assigned
CO/IP Group.
00~99
Networking
Number Plan Bin
This entry defines the Net Number Plan Table bin that
the system will attempt to use for the transit outcall.
001-251
SMDR Code
This is only used for TNET with CM. This code will be
sent to CM when the TNET status is changed from
Local survival mode to bypass mode.
Max. 4 digits
(Include * and #)
4.4.9.4 LCR Table Initialization - PGM 223
Selecting LCR Table Initialization will display the LCR Table Initialization data entry page. Click the [Initialize]
button to initialize input data.
Figure 4.4.9.4-1 LCR Table Initialization
The LCR Table Initialization allows global values to be assigned to the various Digit Modification Table entries.
In addition, the LCR Leading Digits and LCR Digit Modification Tables can be initialized to the default (no
entries) state.
The CO group range is from 1 to 21 for eMG80/100 and 1 to 201 for eMG800/UCP.
